Progressive ER#
Progressive Clean-Clean Entity Resolution Tutorial. In this notebook we present the pyJedAI approach in the well-known ABT-BUY dataset. Clean-Clean ER in the link discovery/deduplication between two sets of entities.
Dataset: Abt-Buy dataset (D1)
The Abt-Buy dataset for entity resolution derives from the online retailers Abt.com and Buy.com. The dataset contains 1076 entities from abt.com and 1076 entities from buy.com as well as a gold standard (perfect mapping) with 1076 matching record pairs between the two data sources. The common attributes between the two data sources are: product name, product description and product price.
How to install?#
pyJedAI is an open-source library that can be installed from PyPI.
For more: pypi.org/project/pyjedai/
!pip install pyjedai -U
!pip show pyjedai
Name: pyjedai
Version: 0.1.3
Summary: An open-source library that builds powerful end-to-end Entity Resolution workflows.
Home-page:
Author:
Author-email: Konstantinos Nikoletos <nikoletos.kon@gmail.com>, George Papadakis <gpapadis84@gmail.com>, Jakub Maciejewski <jacobb.maciejewski@gmail.com>, Manolis Koubarakis <koubarak@di.uoa.gr>
License: Apache Software License 2.0
Location: c:\users\nikol\anaconda3\envs\d31\lib\site-packages
Requires: faiss-cpu, gensim, matplotlib, matplotlib-inline, networkx, nltk, numpy, optuna, ordered-set, pandas, pandas-profiling, pandocfilters, plotly, py-stringmatching, PyYAML, rdflib, rdfpandas, regex, scipy, seaborn, sentence-transformers, strsim, strsimpy, tomli, tqdm, transformers, valentine
Required-by:
Imports
import os
import sys
import pandas as pd
import networkx
from networkx import draw, Graph
import pyjedai
from pyjedai.utils import (
text_cleaning_method,
print_clusters,
print_blocks,
print_candidate_pairs
)
from pyjedai.evaluation import Evaluation
[nltk_data] Downloading package stopwords to
[nltk_data] C:\Users\nikol\AppData\Roaming\nltk_data...
[nltk_data] Package stopwords is already up-to-date!
Data Reading#
pyJedAI in order to perfrom needs only the tranformation of the initial data into a pandas DataFrame. Hence, pyJedAI can function in every structured or semi-structured data. In this case Abt-Buy dataset is provided as .csv files.
from pyjedai.datamodel import Data
from pyjedai.evaluation import Evaluation
d1 = pd.read_csv("./../data/ccer/D2/abt.csv", sep='|', engine='python', na_filter=False)
d2 = pd.read_csv("./../data/ccer/D2/buy.csv", sep='|', engine='python', na_filter=False)
gt = pd.read_csv("./../data/ccer/D2/gt.csv", sep='|', engine='python')
data = Data(dataset_1=d1,
id_column_name_1='id',
dataset_2=d2,
id_column_name_2='id',
ground_truth=gt)
pyJedAI offers also dataset analysis methods (more will be developed)
data.print_specs()
------------------------- Data -------------------------
Type of Entity Resolution: Clean-Clean
Dataset-1:
Number of entities: 1076
Number of NaN values: 0
Attributes:
['name', 'description', 'price']
Dataset-2:
Number of entities: 1076
Number of NaN values: 0
Attributes:
['name', 'description', 'price']
Total number of entities: 2152
Number of matching pairs in ground-truth: 1076
--------------------------------------------------------
data.dataset_1.head(5)
| id | name | description | price | |
|---|---|---|---|---|
| 0 | 0 | Sony Turntable - PSLX350H | Sony Turntable - PSLX350H/ Belt Drive System/ ... | |
| 1 | 1 | Bose Acoustimass 5 Series III Speaker System -... | Bose Acoustimass 5 Series III Speaker System -... | 399 |
| 2 | 2 | Sony Switcher - SBV40S | Sony Switcher - SBV40S/ Eliminates Disconnecti... | 49 |
| 3 | 3 | Sony 5 Disc CD Player - CDPCE375 | Sony 5 Disc CD Player- CDPCE375/ 5 Disc Change... | |
| 4 | 4 | Bose 27028 161 Bookshelf Pair Speakers In Whit... | Bose 161 Bookshelf Speakers In White - 161WH/ ... | 158 |
data.dataset_2.head(5)
| id | name | description | price | |
|---|---|---|---|---|
| 0 | 0 | Linksys EtherFast EZXS88W Ethernet Switch - EZ... | Linksys EtherFast 8-Port 10/100 Switch (New/Wo... | |
| 1 | 1 | Linksys EtherFast EZXS55W Ethernet Switch | 5 x 10/100Base-TX LAN | |
| 2 | 2 | Netgear ProSafe FS105 Ethernet Switch - FS105NA | NETGEAR FS105 Prosafe 5 Port 10/100 Desktop Sw... | |
| 3 | 3 | Belkin Pro Series High Integrity VGA/SVGA Moni... | 1 x HD-15 - 1 x HD-15 - 10ft - Beige | |
| 4 | 4 | Netgear ProSafe JFS516 Ethernet Switch | Netgear ProSafe 16 Port 10/100 Rackmount Switc... |
data.ground_truth.head(3)
| D1 | D2 | |
|---|---|---|
| 0 | 206 | 216 |
| 1 | 60 | 46 |
| 2 | 182 | 160 |
Data cleaning step (optional)#
pyJedAI offers 4 types of text cleaning/processing.
Stopwords removal
Punctuation removal
Numbers removal
Unicodes removal
data.clean_dataset(remove_stopwords = False,
remove_punctuation = False,
remove_numbers = False,
remove_unicodes = False)
Block Building#
It clusters entities into overlapping blocks in a lazy manner that relies on unsupervised blocking keys: every token in an attribute value forms a key. Blocks are then extracted, possibly using a transformation, based on its equality or on its similarity with other keys.
The following methods are currently supported:
Standard/Token Blocking
Sorted Neighborhood
Extended Sorted Neighborhood
Q-Grams Blocking
Extended Q-Grams Blocking
Suffix Arrays Blocking
Extended Suffix Arrays Blocking
from pyjedai.block_building import (
StandardBlocking,
QGramsBlocking,
ExtendedQGramsBlocking,
SuffixArraysBlocking,
ExtendedSuffixArraysBlocking,
)
/home/conda/miniconda3/envs/pyjedai-progressive/lib/python3.9/site-packages/tqdm/auto.py:21: TqdmWarning: IProgress not found. Please update jupyter and ipywidgets. See https://ipywidgets.readthedocs.io/en/stable/user_install.html
from .autonotebook import tqdm as notebook_tqdm
bb = StandardBlocking()
blocks = bb.build_blocks(data, attributes_1=['name', 'description'], attributes_2=['name', 'description'])
Standard Blocking: 100%|██████████| 2152/2152 [00:00<00:00, 21279.99it/s]
bb.report()
Method name: Standard Blocking
Method info: Creates one block for every token in the attribute values of at least two entities.
Parameters: Parameter-Free method
Attributes from D1:
name, description
Attributes from D2:
name, description
Runtime: 0.1018 seconds
_ = bb.evaluate(blocks, with_classification_report=True)
***************************************************************************************************************************
Μethod: Standard Blocking
***************************************************************************************************************************
Method name: Standard Blocking
Parameters:
Runtime: 0.1018 seconds
───────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
Performance:
Precision: 0.12%
Recall: 99.81%
F1-score: 0.25%
───────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
Classification report:
True positives: 1074
False positives: 874536
True negatives: 1156698
False negatives: 2
Total comparisons: 875610
───────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
Block Purging#
Optional step
Discards the blocks exceeding a certain number of comparisons.
from pyjedai.block_cleaning import BlockPurging
bp = BlockPurging()
cleaned_blocks = bp.process(blocks, data, tqdm_disable=False)
Block Purging: 100%|██████████| 4096/4096 [00:00<00:00, 838778.89it/s]
bp.report()
Method name: Block Purging
Method info: Discards the blocks exceeding a certain number of comparisons.
Parameters:
Smoothing factor: 1.025
Max Comparisons per Block: 11845.0
Runtime: 0.0060 seconds
_ = bp.evaluate(cleaned_blocks)
***************************************************************************************************************************
Μethod: Block Purging
***************************************************************************************************************************
Method name: Block Purging
Parameters:
Smoothing factor: 1.025
Max Comparisons per Block: 11845.0
Runtime: 0.0060 seconds
───────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
Performance:
Precision: 0.26%
Recall: 99.81%
F1-score: 0.52%
───────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
Block Cleaning#
Optional step
Its goal is to clean a set of overlapping blocks from unnecessary comparisons, which can be either redundant (i.e., repeated comparisons that have already been executed in a previously examined block) or superfluous (i.e., comparisons that involve non-matching entities). Its methods operate on the coarse level of individual blocks or entities.
from pyjedai.block_cleaning import BlockFiltering
bf = BlockFiltering(ratio=0.8)
filtered_blocks = bf.process(cleaned_blocks, data, tqdm_disable=False)
Block Filtering: 100%|██████████| 3/3 [00:00<00:00, 94.76it/s]
bf.evaluate(filtered_blocks)
***************************************************************************************************************************
Μethod: Block Filtering
***************************************************************************************************************************
Method name: Block Filtering
Parameters:
Ratio: 0.8
Runtime: 0.0326 seconds
───────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
Performance:
Precision: 0.68%
Recall: 99.26%
F1-score: 1.35%
───────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────
{'Precision %': 0.6797958066528331,
'Recall %': 99.25650557620817,
'F1 %': 1.3503432754674995,
'True Positives': 1068,
'False Positives': 156038,
'True Negatives': 1156692,
'False Negatives': 8}
Progressive Entity Resolution#
Scheduling + Emission + Matching
Progressive Entity Resolution (PER) consists of the above three stages. Specifically:
1. Scheduling - This step is similar to Comparison Cleaning. We extract a subset of the original fully connected dataset in which each entity could be a duplicate candidate for any other entity. This is done by deriving neighborhoods for each entity, which contain its duplicate candidates.
2. Emission - We iterate over the previously derived neighborhoods following a wide variety of algorithms (BFS, DFS, Hybrid etc.) and we extract the final candidate pairs. The number of emissions is limited by our budget.
3. Matching - The candidate pairs are evaluated on the premise of being true duplicates. PER methods allow for the calculation of cumulative recall and as a result give us the possibility of deriving AUCs and plotting ROCs for different budget limitations.
The following workflows are currently supported:
NN workflows - Progressive Vector Based BB (EmbeddingsNNBPM)
Join workflows - Base/Vector Based Progressive TopKJoin (TopKJoinPM)
MB (Hash Based) workflows - Progressive CEP (GlobalTopPM), Progressive CNP (LocalTopPM)
Sorted Neighborhood workflows - Global Progressive Sorted Neighborhood (GlobalPSNM), Local Progressive Sorted Neighborhood (LocalPSNM)
Scheduling workflows - Progressive Entity Scheduling (PESM)
from pyjedai.prioritization import (
GlobalTopPM,
LocalTopPM,
EmbeddingsNNBPM,
GlobalPSNM,
LocalPSNM,
RandomPM,
PESM,
TopKJoinPM
)
# Maximum number of candidate pair emissions that can be parsed to matching
BUDGET=10000
# Emission Algorithm (DFS/BFS/HB/TOP)
ALGORITHM="BFS"
# Identification Context - defines which dataset is the source and target one (inorder/reverse/bilateral)
# Non-inorder indexing makes sense only in the context of NN and Join PER workflows
# The other ones conduct entity identification in both dataset directions
INDEXING="inorder"
NN PER (Vector Based)#
ennbpm = EmbeddingsNNBPM(language_model="sminilm",
number_of_nearest_neighbors=10,
similarity_search="faiss",
similarity_function="euclidean",
similarity_threshold=0.0
)
# NN PER workflows don't require blocks in order to define neighborhoods
# Entities are vectorized and similarity function is applied (e.x. faiss)
# In an attempt to cluster similar entities into neighborhoods
ennbpm_candidates = ennbpm.predict(data=data,
blocks=None,
budget=BUDGET,
algorithm=ALGORITHM,
indexing=INDEXING
)
JN PER (Join)#
tkjpm = TopKJoinPM(number_of_nearest_neighbors=10,
similarity_function='cosine',
tokenizer='char_tokenizer',
weighting_scheme='tfidf',
qgram=5,
similarity_threshold=0.0
)
tkjpm_candidates = tkjpm.predict(data=data,
blocks=blocks,
budget=BUDGET,
algorithm=ALGORITHM,
indexing=INDEXING
)
Top-K Join Progressive Matching: 0%| | 0/2048 [00:00<?, ?it/s]
Top-K Join (cosine): 0%| | 0/2152 [00:00<?, ?it/s]
Top-K Join (cosine): 50%|█████ | 1081/2152 [00:00<00:00, 9401.81it/s]
Top-K Join (cosine): 81%|████████ | 1741/2152 [00:10<00:02, 138.00it/s]
Top-K Join (cosine): 81%|████████ | 1741/2152 [00:10<00:02, 138.00it/s]
Top-K Join (cosine): 81%|████████ | 1748/2152 [00:10<00:02, 136.82it/s]
Top-K Join (cosine): 100%|██████████| 2152/2152 [00:17<00:00, 124.81it/s]
Top-K Join Progressive Matching: 0%| | 0/2048 [00:18<?, ?it/s]
MB PER (Metablocking Based)#
ltpm = LocalTopPM(weighting_scheme="SN-CBS",
number_of_nearest_neighbors=10,
similarity_threshold=0.0
)
# Meta Blocking PER workflows allow for the purging and filtering of initial blocks
# To limit the search space
ltpm_candidates = ltpm.predict(data=data,
blocks=filtered_blocks,
budget=BUDGET,
algorithm=ALGORITHM,
indexing=INDEXING
)
Global Top Progressive Matching: 0%| | 0/2022 [00:00<?, ?it/s]
SN PER (Sorted Neighborhood)#
gpsnm = GlobalPSNM(weighting_scheme='ACF',
window_size=10,
similarity_threshold=0.0)
gpsnm_candidates = gpsnm.predict(data=data,
blocks=blocks,
budget=BUDGET,
algorithm=ALGORITHM,
indexing=INDEXING
)
Global Progressive Sorted Neighborhood Matching: 0%| | 0/2048 [00:00<?, ?it/s]
Evaluation (AUC & ROC)#
An ROC curve (receiver operating characteristic curve) is a graph showing the performance of a classification model at all classification thresholds. This curve plots two parameters:
Number of emitted candidate pairs (x Axis)
Cumulative Recall (y Axis)
AUC stands for “Area under the ROC Curve.” That is, AUC measures the entire two-dimensional area underneath the entire ROC curve. AUC provides an aggregate measure of performance across the number of emitted pairs. It provides a visual and very intuitive tool to compare different PER workflows and spot patterns across the whole span of emissions.
matchers = [ennbpm, tkjpm, ltpm, gpsnm]
%%time
progressive_matchers_evaluator = Evaluation(data)
progressive_matchers_evaluator.evaluate_auc_roc(matchers = matchers, proportional = False)
CPU times: user 183 ms, sys: 112 ms, total: 294 ms
Wall time: 176 ms
print("NN WORKFLOW:")
print(f'Total Emissions: {ennbpm.get_total_emissions()}')
print(f'Cumulative Recall: {ennbpm.get_cumulative_recall()}')
print(f'Normalized AUC: {ennbpm.get_normalized_auc()}')
NN WORKFLOW:
Total Emissions: 10000
Cumulative Recall: 0.9684014869888475
Normalized AUC: 0.8500531917068019
print("JOIN WORKFLOW:")
print(f'Total Emissions: {tkjpm.get_total_emissions()}')
print(f'Cumulative Recall: {tkjpm.get_cumulative_recall()}')
print(f'Normalized AUC: {tkjpm.get_normalized_auc()}')
JOIN WORKFLOW:
Total Emissions: 10000
Cumulative Recall: 0.9693308550185874
Normalized AUC: 0.8705726081666761
print("MB WORKFLOW:")
print(f'Total Emissions: {ltpm.get_total_emissions()}')
print(f'Cumulative Recall: {ltpm.get_cumulative_recall()}')
print(f'Normalized AUC: {ltpm.get_normalized_auc()}')
MB WORKFLOW:
Total Emissions: 10000
Cumulative Recall: 0.9163568773234201
Normalized AUC: 0.8116456941666359
print("SN WORKFLOW:")
print(f'Total Emissions: {gpsnm.get_total_emissions()}')
print(f'Cumulative Recall: {gpsnm.get_cumulative_recall()}')
print(f'Normalized AUC: {gpsnm.get_normalized_auc()}')
SN WORKFLOW:
Total Emissions: 10000
Cumulative Recall: 0.7620817843866171
Normalized AUC: 0.6066398007039242
